CAROLINE R. BAUMAL and JAY S. DUKER
Table Of Contents
VIRAL CHARACTERISTICS AND EPIDEMIOLOGY|
|Before 1982, cytomegalovirus (CMV) retinitis was a disease so extraordinarily rare that few ophthalmologists ever observed a case.1 However, because of the acquired immunodeficiency syndrome (AIDS) pandemic, CMV retinitis has now emerged as a common cause of infectious retinitis worldwide. As a consequence, large amounts of data have been compiled concerning the virus's clinical presentation, pattern of infection, disease course, and complications. CMV produces progressive retinal destruction leading to blindness unless anti-CMV treatment is commenced or the underlying cause of systemic immunocompromise is reversed. Multiple new medications displaying in vitro and in vivo anti-CMV efficacy are now available for this previously untreatable infection.2|
|VIRAL CHARACTERISTICS AND EPIDEMIOLOGY|
|Cytomegalovirus is a double-stranded DNA virus belonging to the human herpesvirus
family.1,3 Other members include herpes simplex virus, varicella zoster virus (VZV), and
Epstein-Barr virus. Although CMV is indistinguishable from the
other herpesviruses by electron microscopy, its histopathologic appearance, culture
characteristics, and antigenic signature usually enable
isolation and differentiation with modern laboratory evaluation of infected
material.3 Clinical characteristics of systemic CMV infections were initially described
in 1905.4 In the 1920s, CMV infections, which were at the time referred to as salivary
gland disease, were recognized to be virally mediated.3,5 Later, CMV disease became known as cytomegalic inclusion disease because
of the characteristic cellular inclusions the virus produced on light
microscopy. One of the major target organs for CMV is the retina.6 Although the virus was a known human pathogen, CMV infection of the retina
was not described until the 1950s.7,8 The virus was proven to be the causative agent in presumed CMV retinitis
CMV is transmitted systemically by way of infected blood products, bodily secretions, or across the placenta.1 In developed countries, exposure to CMV usually occurs in childhood or early adulthood. Incidence of CMV seropositivity increases with age. By age 35, nearly all persons living in North America have been exposed to CMV and over 80% will continue to show detectable circulating antibodies to the virus.5,10 Incidence of serologically confirmed CMV infections in newborns is between 0.5% and 2.5%.5,10 Fortunately, only 10% of newborns with laboratory evidence of CMV infection show clinical manifestations of the virus. In immunocompetent persons, CMV infection rarely produces clinical disease. However, CMV is an important cause of morbidity and mortality in immunocompromised individuals. Severe systemic CMV infections occur almost exclusively in persons with abnormal cell-mediated immunity and thus affects two major categories of individuals; the immunosuppressed and newborns. After exposure and systemic infection by CMV, whether it occurs during early development or later in life, the virus typically attains a dormant state within specific cells of the host.11 During periods of severe immunosuppression, CMV virus appears to reactivate and infect the retina through hematogenous spread.12
Infection by the human immunodeficiency virus (HIV) is the most common cause of immunosuppression leading to reactivation of CMV and symptomatic infection. Severe CMV infection has also been associated with congenital immunodeficiency syndromes, pharmacologic immunosuppression, organ transplantation, and malignancy and autoimmune disorders.13 CMV is the major cause of ocular morbidity in HIV infected individuals.11,14 Before the introduction of potent antiretroviral therapy for patients with AIDS, the reported estimates for the prevalence of CMV retinitis varied between 10% and 40%.14–17 CMV retinitis was bilateral at presentation in approximately one third of patients.15 CMV was the AIDS-defining diagnosis in about 5% of patients with HIV infections.15,17,18 Certain subpopulations of patients with AIDS appear to have a lower incidence of CMV retinitis.15,19 Pediatric patients with AIDS have a relatively low incidence of CMV retinitis, probably because they are less likely than adults to have been previously exposed to the virus.20,21
Aside from the retina, symptomatic CMV infection can involve the reticuloendothelial system, liver, kidneys, lungs, gastrointestinal system, and central nervous system in immunosuppressedindividuals. It is believed that the presence of active CMV retinitis almost invariably means that a systemic infection is present. However, the systemic disease may be subclinical. The onset of CMV retinitis appears to depend greatly on the CD4+ T-lymphocyte cell count in adults with AIDS. In children, an age-adjusted CD4 count should be considered.21 The risk for CMV retinitis increases as the CD4 cell count decreases. The mean CD4 cell count at the time of CMV diagnosis is typically less than 50 cells/mm3. It is rare for patients with CD4 counts above 200 cells/mm3 to develop the disease, although it may occur in an individual who previously had a CD4 count less than 50 cells/mm3 and is experiencing an initially favorable response with an elevated CD4 count to highly active antiretroviral therapy (HAART).2
Widespread use of HAART in developed countries has led to improvement in survival of patients with AIDS, reduction of all opportunistic infections including CMV retinitis, increased CD4 lymphocyte cell counts, and decreased HIV viral load.22 Treatment with HAART comprises a combination of medications including protease inhibitors alone or in combination with nucleoside analogues. Epidemiologic data gathered since the introduction of HAART are limited. A retrospective study found a decrease in the incidence of primary and relapsing CMV disease, CMV viral load, and CMV antigenemia in AIDS patients associated with the introduction of HAART therapy.23 However, CMV disease may develop or recur in patients in whom HAART has failed. Immune recovery may be incomplete following HAART and may not fully protect against development of CMV retinitis. Thus, CMV retinitis still appears to be a prevalent opportunistic infection in AIDS and it is important to be aware of its features and treatment of this disorder. The new entity of immune recovery uveitis has been characterized in patients with CMV retinitis who are being treated with HAART.24,25 Moreover, discontinuation of anti-CMV therapy in AIDS patients with improved immune function is now an option for this disorder that previously required life-long anti-CMV treatment.26
|At the onset, CMV retinitis may produce few symptoms, giving scant evidence
for the infection's potential to cause severe visual loss.11 The presence of symptoms is often related to the retinal location involved. CMV
retinitis affecting the posterior pole tends more often to be
symptomatic than peripherally located retinitis. Gradual onset of floaters, scintillating
scotoma, decreased peripheral or central vision, or
metamorphopsia may be noted. However it is not unusual for active
infection to be noted initially on routine screening examination. Immediate, acute
loss of central vision early in the disease course rarely
occurs, although nearly 75% of patients present with disease that is
considered immediately sight-threatening by the ophthalmologist.2 Loss of peripheral vision or a scotoma usually causes affected persons
to seek medical attention before central visual loss from direct macular
destruction. Pain, external injection, or evidence of more than a
mild anterior uveitis is extremely unusual with AIDS-associated CMV retinitis.|
The hallmark lesion of CMV retinitis is a necrotizing, full-thickness retinitis that results in retinal cell destruction. CMV often initially affects retinal tissue adjacent to major retinal blood vessels or the optic disc (Fig. 1). This is consistent with the concept that the virus is spread to the retina hematogenously. In most cases, the pattern of infection is classic and distinctive, making clinical diagnosis straightforward. The area of active retinitis has a granular, dirty-white appearance. As the virus attacks the endothelial cells of blood vessels, hemorrhage is common. Advancement in the retinitis by both direct cell-to-cell transmission as well as spread by way of adjacent satellite lesions can be seen. Except for cases in which retinitis is acute, it is common to see areas of healed retinitis beside areas of active necrosis. Areas of burned-out necrosis show absence of any retinal tissue, whereas the underlying retinal pigment epithelium assumes a “salt and pepper” appearance. CMV retinitis can present initially as either large areas of retinal necrosis with hemorrhage or one or more small, focal areas of retinal whitening.1,12,14 These small, focal lesions may on occasion be confused with cotton-wool spots or lesions of toxoplasmosis.5,27 Unlike cotton-wool spots, focal areas of CMV may appear outside the posterior pole. These early, focal infiltrates of CMV may not be associated with retinal hemorrhages or vitreous cells.
Over a course that usually spans weeks, infiltrates of CMV tend to assume two different patterns of clinical disease.11,12 The first pattern is called hemorrhagic and is characterized by broad geographic zones of retinal whitening. These large, geographic lesions are usually in close proximity to a major retinal blood vessel or the optic nerve. Satellite lesions are common. When the retinal necrosis associated with CMV retinitis becomes widespread, it is almost invariably associated with retinal hemorrhages. Although the border between necrotic and unaffected retina is sharply demarcated, the border itself appears irregular and jagged. Exudation into the retina or subretinal space may be seen, adding to the granular appearance of the retinitis. Juxtaposition of large zones of white, granular necrosis with those of red retinal hemorrhage has led this appearance of CMV retinitis to be described as either “pizza-pie” or “cheese and ketchup.” The retinal blood vessels, both arteries and veins, in the areas of necrosis commonly appear sheathed, secondary to a vasculitis. As a consequence, secondary retinal vascular occlusions, especially branch retinal vein obstructions, may occur in the course of CMV retinitis. Immune-mediated vascular damage may play a role in the vasculitis.12 Central healing of these lesions will occur as the infection progresses. Avasculitis resembling “frosted branch angiitis” hasbeen reported (Fig. 2).28 A second pattern of CMVretinitis has been labeled “granular” or “brushfireborder.” In this appearance, the focal granular infiltrates enlarge slowly across a line, leaving ever-increasing areas of destroyed retina and atrophic retinal pigment epithelium behind. Hemorrhages and vitreous cells are a less prominent feature. There appears to be direct cell-to-cell transfer of infected virions in this pattern of infection (Figs. 3 and 4). The brushfire border is commonly seen in CMV retinitis lesions anterior to the equator (Fig. 5). The significance, if any, of these two clinical patterns of CMV retinitis is not known, and, in some eyes, both patterns of disease can be seen simultaneously or in sequence. Progression of retinitis has been defined in clinical trials as movement of a lesion border at least 750 μm along a front that is 750 μm or more in length, development of a new CMV lesion in a previously involved eye or in the uninvolved fellow eye of a patient with baseline unilateral disease.29 Without treatment or improvement in the host's immune system, CMV retinitis is a relentless, slowly progressive infection resulting in blindness caused by total retinal necrosis, retinal detachment, or optic nerve involvement, in any combination.
CMV infection can affect the optic nerve either directly or by extension from adjacent retinitis (see Fig. 2).30–32 When direct involvement occurs, optic neuritis with profound, irreversible visual loss usually develops. Several cases of CMV optic neuritis associated with adjacent retinitis have been treated successfully. Exudative retinal detachment can occur during the course of CMV retinitis as well.4,12,30 The subretinal fluid is seen primarily inferiorly in the fundus and shifts with position. No retinal break will be evident; however, in areas of extremely thin, atrophic retina, it can be quite difficult to determine whether a full-thickness defect is present. Exudative retinal detachment associated with CMV is usually nonprogressive and may respond to ganciclovir therapy.
Other features may include a mild to moderate anterior chamber cell and flare reaction. A hypopyon has rarely been reported in a renal transplant patient.4 Although mild vitreous cells are almost universally present, a florid vitritis severe enough to result in media opacity rarely develops from isolated CMV retinitis. In one patient who was immunosuppressed as a result of systemic corticosteroid therapy, a severe panuveitis associated with CMV retinitis was reported.32 More recently, an entity called immune recovery retinitis has been described.26,27 Immune-recovery uveitis is a chronic inflammatory syndrome associated with clinical immune reconstitution in AIDS patients with CMV retinitis who are taking HAART.33–35 It has emerged as an important cause of visual morbidity. Although immune recovery associated with HAART has allowed some patients to discontinue specific anti-CMV therapy, the rejuvenated immune response can be associated with this sight-threatening inflammation in some patients with preexisting CMV retinitis. Ocular features of immune-recovery uveitis include a significant vitritis that is more pronounced than that occurring with primary CMV retinitis. Additional features may include optic disc and macular edema. The mean CD4+ T-lymphocyte count in one study was 393 cells/mm3 at the time of diagnosis.33 Long-term vision-threatening complications related to this persistent inflammation include proliferative vitreoretinopathy, epiretinal membrane formation, posterior subcapsular cataracts, and severe postoperative inflammation.36
Rhegmatogenous retinal detachment occurs in 10% to 20% of eyes with CMV retinitis.37–39 However, before the AIDS epidemic, there were only five reported cases of this association.10,40 In patients living more than 1 year with CMV retinitis, risk of retinal detachment may be as high as 50%,41 which increases if more than 25% of peripheral retina is involved by disease.41,42 Retinal breaks in eyes with CMV retinitis typically occur within or at the border of necrotic atrophic retina (Fig. 6).43 The ensuing retinal detachments are typically difficult to repair with standard scleral buckling procedures. This is because of the location and number of retinal breaks, the difficulty in visualizing all breaks in necrotic retina, and the high incidence of associated proliferative vitreoretinopathy. In many cases, pars plana vitrectomy and retinal tamponade with silicone oil or long-acting intraocular gas is indicated (Figs. 7 and 8).37,44,45 However, scleral buckling may be considered in small peripheral retinal detachments when the entire involved area can be completely placed on the element. Laser photocoagulation demarcation has also been described to delimit macula-sparing CMV-related retinal detachment.46 Although anatomic success of macular reattachment with surgery is high, the visual results are often limited by the underlying disease process.47 When considering surgical repair of CMV-induced retinal detachment, consideration should be given to the potential for ambulatory vision, the patient's systemic condition and the status of the fellow eye.
|Diagnosis of CMV retinitis is primarily made on a clinical basis.2 In most cases, ophthalmoscopic examination combined with clinical history
is sufficient to confirm the diagnosis. Because the disease usually
spreads slowly, a period of close careful observation aided by funduscopic
photographic documentation may be considered when the diagnosis
remain uncertain.11 Although most patients with CMV retinitis have concurrent diffuse systemic
CMV infection as well, most of the time they remain systemically
asymptomatic. Given that nearly all immunosuppressed patients who are
at risk for CMV retinitis will show serologic or culture evidence of the
virus in bodily fluids, documented CMV viremia alone, or combined with
viruria does not confirm the diagnosis of CMV retinitis.11|
Tissue diagnosis of CMV retinitis can be obtained, although an invasive procedure to obtain infected retinal tissue carries potential risk. A retinal biopsy during retinal detachment repair may be performed in the setting of a rhegmatogenous retinal detachment with areas of detached, necrotic retina when the diagnosis is unclear.37,39 Retina biopsy may show cytomegalic cells, although severe tissue necrosis may preclude this finding.
Standard culture of an aqueous or vitreous sample is typically of little assistance in diagnosing CMV retinitis because of the limited involvement of these tissues. Newer techniques such as polymerase chain reaction (PCR) allow detection of CMV DNA from small amounts of intraocular fluid and subsequent diagnosis.48 CMV PCR has demonstrated that aqueous and vitreous specimens can provide accurate markers to differentiate active and inactive CMV retinitis.49 Additionally, these markers were superior to extraocular measures, such as plasma PCR and blood and urine CMV cultures. A direct correlation was identified between the quantity of CMV DNA in aqueous humor or vitreous specimens and the corresponding surface area of active CMV retinitis. This technique may be useful in cases where diagnosis is uncertain or when visualization of the retina is obscured, although it is primarily available as a research tool.
The efficacy of screening asymptomatic patients at risk for CMV retinitis has not been clearly defined. It has been recommended to screen AIDS patients based on their CD4 lymphocyte count. Many patients may be asymptomatic with active retinitis and earlier diagnosis and treatment should result in less extension of CMV into the macula. In addition, reduction of the area of necrotic retina may decrease the incidence of CMV-related retinal detachment.
|Treatment for CMV infections and retinitis has improved significantly over
the last decade.50 Principles of therapy include reversal of the underlying cause of immunosuppression
if possible and medications with specific anti-CMV activity. In
patients who develop CMV retinitis after organ transplantation, reduction
of immunosuppressants if medically possible was the treatment
before the availability of anti-CMV drugs. In some AIDS patients, this
is now possible with the use of HAART. There are scattered reports
of antiretroviral therapy (e.g., zidovudine) alone inducing regression
of CMV retinitis.51 Before the availability of ganciclovir and fos-carnet, other medical therapies
were tried but none proved effective. These included corticosteroids, γ-globulin, antifungal agents, vidarabine, human leukocyte
interferon, interferon α, and acyclovir.10,52 In the 1980s, two drugs became available for intravenous treatment of
retinitis-ganciclovir and foscarnet. These agents have proven effective
initially to halt CMV retinitis. However, these drugs are virostatic, poorly
absorbed, and associated with significant systemic toxicities
that often limit their use. More recently, four additional treatment options
have been approved including oral ganciclovir, intravenous cidofovir, the
ganciclovir implant, and intravitreal fomivirsen (Vitravene) injection. These
newer remedies avoid the requirement of chronic venous
access, daily intravenous therapy and its attendant negative impact
on quality of life, and provide the latest option of local therapy.|
Ganciclovir is an acyclic nucleoside that is a congener of acyclovir, but it is between 10 and 100 times more effective against CMV.11,15,53 Most isolates of CMV are inhibited by 0.1 to 0.3 μg/ml.53 Virostatic intravenous levels can be achieved with intravenous doses of 2.3 to 5 mg/kg.54 Ganciclovir is also active against the other members of the herpesvirus family (herpes simplex virus, VZV). The recommended intravenous dosage of ganciclovir is 5 to 7.5 mg/kg.2,11 Initially, during the induction phase of treatment, the drug is given twice a day for 2 to 3 weeks. Clearing of active retinitis usually takes several weeks.11 Maintenance therapy usually consists of5 mg/kg once a day, five or seven times per week.2,11,55 If ganciclovir therapy is stopped and the patient remains immunocompromised, recrudescence is usually seen within 4 weeks.11 The initial response rate to intravenous ganciclovir induction varies from 80% to 100%, but reactivation of CMV retinitis during maintenance therapy is common and expected in immunocompromised individuals.2,12,55,56 This has been attributed to low ocular drug bioavailability, progressive decline in immune function and development of CMV resistance to ganciclovir. Resistance to ganciclovir has been associated with a mutation in both the UL97 and UL54 genes.57 Evidence indicates that ganciclovir-treated AIDS patients with CMV retinitis live longer than those who receive no treatment.58 Additionally, patients who show a complete response to ganciclovir appear to live longer than those whose response is only partial.55 Despite ganciclovir treatment, contralateral CMV retinitis may develop in up to 15% of previously unaffected eyes.17 Ganciclovir carries significant bone marrow toxicity. Overall, up to 70% of treated patients may develop some degree of bone marrow suppression.2,55 Severe thrombocytopenia as well as neutropenia can develop, requiring cessation of intravenous therapy. Although bone marrow suppression may limit the dosing, the availability of hematopoietic stimulating factors (i.e., granulocyte-colony stimulating factor, granulocyte monocyte-colony stimulating factor) has permitted improved tolerance of ganciclovir.
The second intravenous agent approved for the treatment of CMV retinitis was foscarnet. Foscarnet (trisodium phosphoformate) is a synthetic, water-soluble pyrophosphate analogue that inhibits in vitro replication of the herpesviruses.2,11,12,39 Its activity is through noncompetitive binding to the exchange site of viral DNA polymerase, thereby rendering it inactive. Foscarnet lacks the bone marrow toxicity of ganciclovir, allowing for its concurrent use with zidovudine. It requires extensive hydration during intravenous therapy, and it may induce nephrotoxicity and seizures.2,59 The induction regimen for foscarnet is 60 mg/kg every 8 hours or 90 mg/kg twice daily.2,59 It is usually initiated for 2 to 3 weeks, followed by maintenance therapy at 90 to 120 mg/kg/day. The efficacy of foscarnet to induce regression of retinitis and maintain CMV inactivity mirrors that of intravenous ganciclovir very closely.2,60 The Studies of the Ocular Complications of AIDS (SOCA) Research Group showed that the two drugs appear equivalent in controlling CMV retinitis and preserving vision, although foscarnet may be associated with longer survival than ganciclovir.60 In general, however, ganciclovir appears to be better tolerated than foscarnet for long-term therapy.
Besides their side effects, both ganciclovir and foscarnet have important disadvantages. Neither is viricidal, so their use must be maintained for as long as the affected individual remains immunosuppressed.2,55 The relapse rate during maintenance therapy is high. Relapses may be controlled by reinduction with either agent or a combination of both intravenous ganciclovir and foscarnet. The improved efficacy of this combination in controlling relapsing retinitis is counteracted by its side effects and negative impact on quality of life measures.61 For this reason, combination therapy is reserved for severely resistant cases. An alternative to combination intravenous therapy that is now available would be placement of a ganciclovir intraocular implant combined with intravenous or intravitreal foscarnet. Either foscarnet or ganciclovir is typically administered intravenously for induction. This often requires placement of a permanent intravenous access system with the subsequent risk of infection. Finally, both drugs are costly and frequent dosing is time consuming and inconvenient for the patient.
An oral form of ganciclovir became available in the mid 1990s. It is used as maintenance therapy in patients who respond well to initial intravenous induction with ganciclovir. However, it has poor ocular bioavailability. This necessitates the use of large doses (ranging between 3 to 6 g per day) and the median time interval to progression of retinitis is less with oral ganciclovir than the intravenous form (29 versus 49 days respectively).62 The risk of developing CMV retinitis in the contralateral eye is greater with oral than with intravenous ganciclovir. Oral ganciclovir appears to play a role in decreasing the risk of fellow eye retinitis in patients with unilateral CMV retinitis who are treated with local therapy such as the ganciclovir implant.63 A prodrug of oral ganciclovir with improved bioavailability is currently under study.
Cidofovir (also known as HPMPC) is an antiviral nucleotide analogue with significant activity against CMV and other herpesviruses. Cidofovir has a long intracellular half-life that allows for a prolonged interval of 2 weeks between intravenous maintenance doses, compared with daily administration of intravenous ganciclovir and foscarnet.64 The efficacy of intravenous cidofovir has been demonstrated in patients with AIDS and previously untreated CMV retinitis in multicenter randomized trials, and in a dose-finding study of cidofovir in patients with AIDS and previously treated relapsing CMV retinitis.65,66 Clinical trials have involved relatively small numbers of patients and no studies have beenconducted directly comparing intravenous cido-fovir with either ganciclovir or foscarnet. Indirectcomparisons of clinical trial data suggest that in-travenous cidofovir may have similar efficacy tointravenous ganciclovir or foscarnet in delaying progression of CMV retinitis. However, such comparisons must be made cautiously because of differences in study design and examination techniques.
Despite this, intravenous cidofovir is less invasive and more convenient for patients because of its prolonged dosage interval. In addition, an indwelling central venous catheter is not required. The long dosage interval for cidofovir may also have favorable implications regarding treatment costs and quality of life. The major treatment-limiting adverse event associated with intravenous cidofovir is potentially irreversible nephrotoxicity. Close monitoring of renal function, hydration, and simultaneous administration of probenecid on treatment days are required. An anterior uveitis syndrome has been reported in up to 40% of patients 67 and a small number of patients have developed hypotony.
Cidofovir and ganciclovir appear to have a synergistic effect inhibiting CMV replication in vitro. A phase I study suggested that intravenous cidofovir (5 mg/kg intravenously every 2 weeks) combined with oral ganciclovir might enhance treatment efficacy in AIDS-related CMV retinitis.68 Notably, this regimen does not require indwelling venous catheter access. Because all the intravenous treatment options for CMV retinitis are associated with potentially serious adverse events, selection of pharmacotherapy should be individualized and depends several factors including lesion characteristics, patient quality of life issues, and efficacy and tolerability profiles of available therapies. While receiving maintenance intravenous therapy, patients are typically examined every 4 weeks for evidence of reactivation of the CMV retinitis. When this occurs, options for further treatment include reinduction, medication switch, combination therapy, or adjunctive local therapy. Fundus photographs are invaluable for assessing the activity of the retinitis from visit to visit and should be repeated whenever a change is suspected.
Local intraocular treatments as alternatives to systemic medications have been a significant advance in management of CMV retinitis. Local ocular therapy has proven effective and provides significant advantages over systemic therapy with regards to control of retinitis, prevention of progression, and avoidance of bone marrow and renal toxicity. Disadvantages of local therapy include the risk of CMV retinitis in the contralateral eye and the lack of protection against systemic extraocular CMV infection.
Animal experiments demonstrated that intravitreal injections in excess of 400 μg of ganciclovir and 1200 μg of foscarnet are nontoxic to the retina.69,70 Intravitreal injection of either ganciclovir or foscarnet, although an unapproved modality, has been used successfully in some patients, especially those with recurrent or refractory disease. Long-term control of CMV retinitis control through repeated intravitreal injections has been evaluated.54,71,72 The published dose of intravitreal ganciclovir is 200 to 400 μg, although many clinicians now use a dose of 2000 μg in 0.1-ml sterile normal saline. This appears to control active CMV retinitis in about 80% of patients. During the induction phase, injections are given three times per week, followed by injections given once or twice per week during long-term maintenance therapy. Multiple injections are required because of the short intraocular drug half-life. About 30% of treated patients develop recurrent disease on this regimen.71,72 As an alternative in patients who are resistant to ganciclovir, intravitreal foscarnet at a dose of up to 2400 μg in 0.1 ml of sterile normal saline may control CMV retinitis.73 No retinal toxicity has been associated with the doses mentioned here. Potentially vision-threatening complications associated with this method such as exogenous endophthalmitis, vitreous hemorrhage, and retinal detachment are uncommon. However, chronic intravitreal injections are not well tolerated because of the inconvenience of frequent injections. Cidofovir has also been administered by intravitreal injection and it has the advantage of a longer intracellular half-life, which would allow less frequent injections. However, it has been associated with multiple side effects including transient or chronic hypotony with permanent visual loss and uveitis. Further study is needed to determine the safety of this agent for intraocular injection and the effective intraocular dose.74
An intraocular ganciclovir implant that delivers this drug in a sustained release fashion is well tolerated and very effective against CMV retinitis. Advantages include less frequent injection than the above intravitreal agents and a constant rate of drug release into the vitreous. This intraocular implant was approved by the U.S. Food and Drug Administration (FDA) in 1996 (Fig. 9).75,76 The implant consists of a pelletized form of ganciclovir covered by a semipermeable membrane. It contains approximately 5 mg of drug, with a release rate of 1.5 μg/hr and the drug lasts between 6 to 8 months. It is placed surgically into the vitreous cavity through a pars plana incision and releases ganciclovir linearly in a time-released fashion (Fig. 10).77,78 The time to progression of CMV retinitis is significantly longer with the ganciclovir implant than with intravenous therapy, but there is also a higher rate of contralateral eye retinitis and systemic CMV disease with the implant (Figs. 11 and 12).79 The implant has been used to treat primary, recurrent, and bilateral retinitis with implantation in each eye. It has also been effective in eyes with silicone oil tamponade for CMV-related retinal detachment.80–82 Complications are uncommon but include macular edema, vitreous hemorrhage, and retina detachment, especially if CMV infection involved more than 25% of the retina. The device can be replaced at approximately 6 months when it is depleted of drug, but some clinicians prefer to observe for early signs of recurrent CMV activity before replacement.83 In addition, multiple implants can be placed in one eye rather than exchanging the implant when it is depleted of drug. A very rare complication was two cases of separation of the ganciclovir medication pellet from the tab of the implant when it was removed.84
The beneficial effect of HAART on the immunologic status and survival in some patients with HIV has altered the incidence of primary and relapsing CMV retinitis. Thus, clinical management of CMV retinitis and the role of the ganciclovir implant are changing.85 The International AIDS Society (U.S.A. panel) concluded that optimal use of the ganciclovir implant and discontinuation of systemic therapy in selected patients with improved immunity due to HAART may result in better long-term visual outcomes.86 In patients who remain chronically immunocompromised and are treated with local therapy, systemic anti-CMV therapy in the form of oral ganciclovir is recommended to avoid CMV infection in the fellow eye as well as symptomatic extraocular CMV disease.63
Fomivirsen (also known as Vitravene or ISIS 2922, manufactured by Ciba Vision) is an antisense oligonucleotide, which specifically inhibits replication of human CMV. It achieves this by binding to complementary sequences on messenger RNA transcribed from a major transcriptional unit of the virus.87,88 It is administered as an intravitreal injection and is an alternative treatment for refractory CMV retinitis. It has a longer intravitreal elimination half-life than either ganciclovir or foscarnet, allowing injections at intervals of 1 week for induction and every 2 weeks for maintenance. Commonly reported side effects include increased intraocular pressure and mild to moderate intraocular inflammation, which is generally transient and reversible with topical steroid drops. Two cases of bull's-eye maculopathy have been reported that were reversible with discontinuation of therapy; this did not appear to affect vision.89
Development of new anti-CMV agents has been slowed by the decreased incidence of the disease. Valganciclovir, a prodrug of ganciclovir, offers excellent oral bioavailability and is the closest to approval of the new anti-CMV drugs. High ganciclovir blood levels are achieved without the complications associated with chronic intravenous access.
Factors to consider in selecting the mode of therapy include the patient's potential for immunologic improvement, the location and severity of CMV retinitis, and the risks, costs, and convenience associated with various therapies. Before introduction of HAART, lifelong anti-CMV therapy was required to prevent progression of CMV retinal disease and subsequent loss of vision in AIDS. The beneficial effect of HAART on the immunologic status of some patients has made the role of maintenance anti-CMV treatment less clear. Maintenance anti-CMV medications have been safely stopped in some small series of AIDS patients with stable inactive CMV retinitis and elevated CD4+ cell counts (above 100 cells/μl) without reactivation of CMV retinitis.26,90,91 Thus, immune recovery following potent HAART may be effective to control a major opportunistic infection, even in patients with a history of previous severe immunosuppression. Patients may be at risk for reactivation of CMV retinitis despite initial favorable response to HAART if their CD4 lymphocyte count falls below 50 cells/mm3.92
|Any entity that produces a focal or diffuse retinitis with or without retinal
hemorrhage in an immunosuppressed host should be considered in
the differential diagnosis of CMV retinitis. Because immunosuppressed
patients can also develop a myriad of other opportunistic ocular infections, the
treatments for which may differ dramatically from CMV retinitis, differentiation
is crucial.11,12 For the most part, the clinical history and a careful ophthalmoscopic
examination of both eyes will be sufficient to identify CMV as the offending
pathogen. In unusual cases, a period of close observation, an empiric
treatment trial with anti-CMV therapy, or even a vitreous or retinal
biopsy may be indicated.|
HIV retinopathy is the entity most likely to be confused with early CMV retinitis.27 It is the most common ocular manifestation of patients with AIDS, occurring in about two thirds of those diagnosed with the disease.15,18 HIV retinopathy consists of multiple, cotton-wool spots, scattered retinal hemorrhages, and is usually bilateral. If these areas of retinal whitening resemble CMV, close observation over a period of days to weeks with documentation by photography is recommended. CMV retinitis will invariably progress, whereas cotton wool spots eventually resolve. HIV retinopathy rarely produces visual loss.
The most important posterior segment infections that may be confused with CMV retinitis are toxoplasmosis, syphilis, and infection with the other herpesviruses (herpes simplex virus, VZV). Toxoplasmosis is often a nonopportunistic infection and generally presents as a focal retinitis with more vitreous cells and less retinal hemorrhages than CMV retinitis does. However, in immunocompromised hosts, Toxoplasma infection can produce a severe, diffuse retinitis.93 Serologic diagnosis may be helpful with toxoplasmosis. Nearly one third of HIV patients have CNS toxoplasmosis concurrently. Ocular syphilis can also mimic CMV retinitis, although the lesions of secondary syphilis are usually a choroiditis rather than a retinitis.94 Serologic testing is invaluable in diagnosing syphilis. Opportunistic infections resulting in the clinical syndrome of multifocal choroiditis such as Pneumocystis carinii infection, histoplasmosis, cryptococcosis, and atypical Mycobacteria should rarely, if ever, be confused with CMV retinitis on ophthalmoscopic examination.
The acute retinal necrosis (ARN) syndrome due to VZV or, more rarely, herpes simplex virus occurs in both healthy persons and the immunosuppressed, including those with AIDS.95 ARN differs from CMV retinitis in that it is typically peripheral in location and much more rapid in course. In addition, vitreous cells are a prominent feature of ARN. A specific type of rapidly progressive ARN with little vitreous reaction associated with VZV in AIDS patients has been described.96 In cases of suspected ARN, intravenous acyclovir is the recommended treatment. If no response is seen, it is reasonable to try foscarnet because it is the drug of choice for acyclovir-resistant herpesviruses. Acyclovir is rarely effective against CMV.
2. Studies of the Ocular Complications of AIDS Research Group: Mortality in patients with the acquired immune deficiency syndrome treated with either foscarnet or ganciclovir for cytomegalovirus retinitis. N Engl J Med 326:213, 1992
25. Zegans ME, Walton RC, Holland GN et al: Transient vitreous inflammatory reactions associated with combination antiretroviral therapy in patients with AIDS and cytomegalovirus retinitis. Am J Ophthalmol 125:292, 1998
29. Holbrook JT, Davis MD, Hubbard LD et al: Risk factors for advancement of cytomegalovirus retinitis in patients with acquire immunodeficiency syndrome: Studies of the Ocular Complications of AIDS Research Group. Arch Ophthalmol 11:1196, 2000
36. Karavellas MP, Song M, Macdonald JC et al: Long-term posterior and anterior segment complications of immune recovery uveitis associated with cytomegalovirus retinitis. Am J Ophthalmol 130:57, 2000
41. Studies of Ocular Complications of AIDS (SOCA) Research Group in Collaboration with the AIDS Clinical Trials Group (ACTG): Rhegmatogenous retinal detachment in patients with cytomegalovirus retinitis: The Foscarnet-Ganciclovir Cytomegalovirus Retinitis Trial. Am J Ophthalmol 124:61, 1997
48. Dodt KK, Jacobsen PH, Hoffman B et al: Development of cytomegalovirus (CMV) disease may be predicted in HIV-infected patients by CMV polymerase chain reaction and the antigenemia test. AIDS 11:F21, 1997
49. Smith IL, Macdonald JC, Freeman WR et al: Cytomegalovirus (CMV) retinitis activity is accurately reflected by the presence and level of CMV DNA in aqueous humor and vitreous. J Infect Dis 179:1249, 1999
57. Jabs DA, Martin BK, Forman MS et al: Mutations conferring ganciclovir resistance in a cohort of patients with acquired immunodeficiency syndrome and cytomegalovirus retinitis.J Infect Dis 183:333, 2001
60. Studies of the Ocular Complications of AIDS Research Group, in collaboration with the AIDS Clinical Trials group: Foscarnet-ganciclovir cytomegalovirus retinitis trial. 4. Visual outcomes. Ophthalmology 101:1250, 1994
61. Studies of Ocular Complications of AIDS Research Group in Collaboration with the AIDS Clinical Trials Group: Combination foscarnet and ganciclovir therapy vs monotherapy for the treatment of relapsed cytomegalovirus retinitis in patients with AIDS: The Cytomegalovirus Retreatment Trial. Arch Ophthalmol 114:23, 1996
63. Martin DF, Kuppermann BD, Wolitz RA et al for the Roche Ganciclovir Study Group: Oral ganciclovir for patients with cytomegalovirus retinitis treated with a ganciclovir implant. N Engl J Med 340:1063, 1999
65. The Studies of Ocular Complications of AIDS Research Group in collaboration with the AIDS Clinical Trials Group: Long-term follow-up of patients with AIDS treated with parenteral cidofovir for cytomegalovirus retinitis: The HPMPC Peripheral Cytomegalovirus Retinitis Trial. AIDS 14:1571, 2000
66. Studies of Ocular Complications of AIDS Research Group in Collaboration with the AIDS Clinical Trials Group: Parenteral cidofovir for cytomegalovirus retinitis in patients with AIDS: The HPMPC peripheral cytomegalovirus retinitis trial. A randomized, controlled trial. Ann Intern Med 126;264, 1997
68. Jacobson MA, Wilson S, Stanley H et al: Phase I study of combination therapy with intravenous cidofovir and oral ganciclovir for cytomegalovirus retinitis in patients with AIDS. Clin Infect Dis 28:528, 1999
74. Taskintuna I, Rahhal FM, Arevalo JF et al: Low-dose intravitreal cidofovir (HPMPC) therapy of cytomegalovirus retinitis in patients with acquired immune deficiency syndrome. Ophthalmology 104:1049, 1997
77. Duker JS, Robinson M, Anand R et al: Initial experience with an eight month sustained-release intravitreal ganciclovir implant for the treatment of CMV retinitis associated with AIDS. Ophthalmic Surg Lasers 26:442, 1995
86. Martin DF, Dunn JP, Davis JL et al: Use of the ganciclovir implant for the treatment of cytomegalovirus retinitis in the era of potent antiretroviral therapy: Recommendations of the International AIDS Society-U.S. A. panel. Am J Ophthalmol 127:329, 1999
92. Song MK, Karavellas MP, MacDonald JC et al: Characterization of reactivation of cytomegalovirus retinitis in patients healed after treatment with highly active antiretroviral therapy. Retina 20:151, 2000
